The best solution when connections with plain bars aren't possible …
RoHS
■ DESCRIPTION
Several copper strips inside PVC
|
■ TECHNICAL SPECIFICATIONS
Copper
Copper Cu-ETP with a minimum
copper content of 99.90%
• Annealed
• Upon NFA 51 050, DIN 40500
• Conductivity : 100 IACS
• HV < 50
• Tensile strength: Rm > 200 N/cm2
• Elongation after break > 35 %
• Resistivity : 1,724 micro Ω /cm à 20 °C
Electrical specifications
• Dielectric rigidity: 20 kV / mm
• Tension of use: 1000V AC / 1500 V DC
• Temperature of use: -40° à +105°C
|
Insulating material
• Self extinguishing black PVC
• Thickness : 1,5 - 2 mm
• Specifications upon BS 6746,
VDE 207 : Y16 et YM4 ; UL 94 VO
• Hardness Shore A : 89 +/- 2
• Elongation: 15% mini
• Breaking restivity: 20 MPa
|
|
|
■ PRESENTATION / PACKAGING
• Length : 2000 mm (-0/+5 mm)
• Marking : MAXIFLEX brand and sizes ( width x thickness x number of strips )
Wooden packaging to the unit or 10
Download
MAXIFLEX CATALOG : Dimensions and permissible intensities (PDF)
ALLOYS QUOTATIONS : Our daily summary
Other non standard dimensions can be proposed on request. Call + 33 4 72 46 09 09.
